Olympus GIF-HQ190 EVIS EXERA III HD Video Gastroscope
The Olympus GIF-HQ190 EVIS EXERA III is a refurbished and recertified high-definition video gastroscope designed for diagnostic and therapeutic upper gastrointestinal procedures. It features Dual Focus technology, Narrow Band Imaging, a 140° field of view, a 2.8 mm instrument channel, and a forward water-jet channel.
$13,300.00
Olympus GIF-HQ190 EVIS EXERA III HD Video Gastroscope
The Olympus GIF-HQ190 EVIS EXERA III Video Gastroscope is designed for high-definition diagnostic and therapeutic procedures within the upper gastrointestinal tract.
It features Olympus Dual Focus technology, allowing the operator to switch between normal and near-focus observation modes. Normal focus provides a depth of field from 5 to 100 mm, while near focus offers detailed visualization from 2 to 6 mm.
The scope also supports Olympus Narrow Band Imaging technology, which helps enhance the visibility of mucosal structures and vascular patterns during examination.
With a 140° forward-viewing field of view, the GIF-HQ190 provides broad visualization of the esophagus, stomach, and duodenum. Its 9.9 mm insertion tube and 9.9 mm distal-end diameter support controlled navigation through the upper gastrointestinal tract.
A 2.8 mm instrument channel accommodates compatible endotherapy accessories for procedures such as biopsy, injection, hemostasis, and foreign-body retrieval.
The GIF-HQ190 also includes a forward water-jet channel to help clear the field of view during examination. Its waterproof one-touch connector is fully submersible and eliminates the need for a separate water-resistant cap during reprocessing.
The scope has a working length of 1,030 mm and a total length of 1,350 mm. It is designed for use with the Olympus CV-190 Video System Center and CLV-190 Xenon Light Source.
Key Features
- EVIS EXERA III video gastroscope
- High-definition HDTV image quality
- Olympus Dual Focus technology
- Normal and near-focus observation modes
- Narrow Band Imaging compatibility
- Wide 140° field of view
- Forward-viewing optical system
- 9.9 mm distal-end diameter
- 9.9 mm insertion-tube diameter
- 2.8 mm instrument channel
- Forward water-jet channel
- Four-way tip angulation
- Waterproof one-touch connector
- Fully submersible connector design
- Compatible with the Olympus CV-190 and CLV-190 platform
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Olympus |
| Model | GIF-HQ190 |
| Product Family | EVIS EXERA III |
| Device Type | Video gastroscope |
| Viewing Direction | Forward viewing |
| Field of View | 140° |
| Depth of Field — Normal Focus | 5–100 mm |
| Depth of Field — Near Focus | 2–6 mm |
| Distal-End Diameter | 9.9 mm |
| Insertion-Tube Diameter | 9.9 mm |
| Working Length | 1,030 mm |
| Total Length | 1,350 mm |
| Instrument-Channel Diameter | 2.8 mm |
| Minimum Visible Distance | 3.0 mm from the distal end |
| Up Angulation | 210° |
| Down Angulation | 90° |
| Right Angulation | 100° |
| Left Angulation | 100° |
| Imaging Technologies | HDTV, Dual Focus, and Narrow Band Imaging |
| Auxiliary Water Channel | Yes |
| Connector | Waterproof one-touch connector |
| Video System Compatibility | Olympus CV-190 |
| Light Source Compatibility | Olympus CLV-190 |
