Olympus GIF-Q180 EVIS EXERA II Video Gastroscope
The Olympus GIF-Q180 EVIS EXERA II is a refurbished and recertified slim video gastroscope designed for diagnostic and therapeutic upper gastrointestinal procedures. It features an 8.8 mm insertion tube, a 2.8 mm instrument channel, a 140° field of view, Narrow Band Imaging capability, and an integrated Scope ID function.
$7,980.00
Olympus GIF-Q180 EVIS EXERA II Video Gastroscope
The Olympus GIF-Q180 EVIS EXERA II Video Gastroscope combines high-quality imaging with a slim insertion design for diagnostic and compatible therapeutic procedures within the upper gastrointestinal tract.
The scope has an 8.8 mm distal-end diameter and maintains the same slim 8.8 mm diameter throughout its insertion tube. This design supports controlled insertion and navigation during examination of the esophagus, stomach, and duodenum.
Its forward-viewing optical system provides a wide 140° field of view and a depth of field ranging from 3 to 100 mm. The scope is designed to produce clear images with natural colour reproduction in a large display format.
A 2.8 mm instrument channel accommodates a range of compatible endotherapy accessories while supporting suction and therapeutic applications. Four-way tip angulation provides movement of 210° upward, 90° downward, and 100° to both the right and left.
The GIF-Q180 also incorporates an integrated Scope ID function. A built-in memory chip stores information such as the scope model, serial number, basic specifications, and white-balance settings. This information can be displayed on a compatible system monitor to support equipment identification and endoscopy-suite management.
Narrow Band Imaging is available when the GIF-Q180 is connected to a compatible Olympus CV-180 Video System Center and CLV-180 Xenon Light Source.
The scope has a working length of 1,030 mm and a total length of 1,345 mm. It is compatible with Olympus CV-180, CV-160, and CV-140 video-system platforms.
Key Features
- EVIS EXERA II video gastroscope
- Standard-definition video imaging
- High-quality image reproduction
- Narrow Band Imaging capability with a compatible system
- Slim 8.8 mm distal-end diameter
- Slim 8.8 mm insertion-tube diameter
- Wide 140° field of view
- Forward-viewing optical system
- Depth of field from 3 to 100 mm
- 2.8 mm instrument channel
- Four-way tip angulation
- Integrated Scope ID function
- Built-in scope-information memory chip
- Ergonomically designed control section
- User-programmable scope switches
- 1,030 mm working length
- Compatible with Olympus EVIS EXERA platforms
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Olympus |
| Model | GIF-Q180 |
| Product Family | EVIS EXERA II |
| Device Type | Video gastroscope |
| Image Format | Standard definition |
| Viewing Direction | Forward viewing |
| Field of View | 140° |
| Depth of Field | 3–100 mm |
| Distal-End Diameter | 8.8 mm |
| Insertion-Tube Diameter | 8.8 mm |
| Working Length | 1,030 mm |
| Total Length | 1,345 mm |
| Instrument-Channel Diameter | 2.8 mm |
| Minimum Visible Distance | 3 mm from the distal end |
| Up Angulation | 210° |
| Down Angulation | 90° |
| Right Angulation | 100° |
| Left Angulation | 100° |
| Narrow Band Imaging | Yes, with a compatible system |
| Scope ID Function | Yes |
| Auxiliary Water Jet | No |
| Video-System Compatibility | Olympus CV-180, CV-160, and CV-140 |
| NBI System Configuration | Olympus CV-180 and CLV-180 |
